It works silently and because it lacks mechanical elements it presents a long useful life without hardly requiring a maintenance. Switchable by means of an internal jumper and can be operated by a control of accesses or by means of a simple pushbutton.

Application:
Robot, electronic applicances, printing machine, automatic stopper, medical equipments, etc.

Specifications:

型號 Type	尺寸 Dimensions (mm)	電壓 Voltage (V)	功率 Power (W)	吸力 Holding force (KG)	安裝孔 Screw holes	自重 Self Weight (g)
NH-P13/27	φ13x(H)27	DC 5V, 6V, 12V, 24V	1W	1	M3	20g
NH-P13/30	φ13x(H)30	DC 5V, 6V, 12V, 24V	1W	1	M4	25g
NH-P20/15	φ20x(H)15	DC 5V, 6V, 12V, 24V	2W	2.5	M4	25g
NH-P25/11	φ25x(H)11	DC 5V, 6V, 12V, 24V	2W	5	M4	28g
NH-P25/20	φ25x(H)20	DC 5V, 6V, 12V, 24V	2W	5	M4	50g
NH-P30/22	φ30x(H)22	DC 5V, 6V, 12V, 24V	3W	10	M4	85g
NH-P30/25	φ30x(H)25	DC 5V, 6V, 12V, 24V	3W	10	M4	98g
NH-P34/18	φ34x(H)18	DC 5V, 6V, 12V, 24V	3W	18	M4	90g
NH-P34/25	φ34x(H)25	DC 5V, 6V, 12V, 24V	3.5W	20	M5	135g
NH-P40/20	φ40x(H)20	DC 5V, 6V, 12V, 24V	3.5W	25	M5	145g
NH-P40/25	φ40x(H)25	DC 5V, 6V, 12V, 24V	4W	30	M5	180g
NH-P49/21	φ49x(H)21	DC 5V, 6V, 12V, 24V	5W	40	M6	215g
NH-P50/27	φ50x(H)27	DC 5V, 6V, 12V, 24V	6W	50	M6	290g
NH-P50/30	φ50x(H)30	DC 5V, 6V, 12V, 24V	7W	60	M6	325g
NH-P59/34	φ59x(H)34	DC 12V, 24V, 36V	10W	70	M8	500g
NH-P65/30	φ65x(H)30	DC 12V, 24V, 36V	10W	80	M10	538g
NH-P70/10	φ70x(H)10	DC 12V, 24V	9W	20	M5	230g
NH-P80/10	φ80x(H)10	DC 12V, 24V	9W	25	M5	260g
NH-P80/38	φ80x(H)38	DC 12V, 24V, 36V	12W	100	M8	1050g
NH-P100/40	φ100x(H)40	DC 12V, 24V, 36V	12W	150	M10	1800g
NH-P120/50	φ120x(H)50	DC 12V, 24V, 36V	15W	350	M12	3300g
NH-P150/50	φ150x(H)50	DC 12V, 24V, 36V	20W	500	M14	7000g

(for referrence only)
